Link ECU Gen3 LS Cable Throttle Bundle: G4X StormX ECU + LS Engine Harness bundle
Gen3 LS Cable Throttle Bundle: G4X StormX ECU + Terminated LS Engine Harness + MAP & Knock adapters
Brand: Link ECU
Part Number: 108-9005B
Description:
A ready-to-go solution to connect a Link ECU to your
Gen 3
(LS1 & LS6)
, Cable Throttle
LS V8 engine.
Features
Advanced features on the StormX ECU:
- Built in trigger oscilloscope.
- Onboard Knock Control – support for two knock sensors wired directly to the ECU. No external amplifier required.
- Boost control can be open or closed loop with up to three switchable tables.
- Idle valve solenoid or stepper motor control.
- Rotary oil metering pump control.
- Most Motorsport features including full gear shift control, antilag and launch control
- Up to 4 fully variable closed loop VVT cams.
The terminated harness has the following features:
- Designed to match the
- PC Link base maps
- IO setup so that most engines can be made to run with minimal adjustments.
- Provides
- spare IO via a "Spares" connector
- — extra capacity for sensors, switches, or custom additions.
- Equipped with
- sealed JPT terminals
- in the chassis connector (TE Connectivity JPT family), with mating connector specs provided.
- The harness includes multiple dedicated
- connectors for key components
, such as:
- Pedal connector
- (for DBW pedal): 5V, sensor ground, two analog voltage inputs
- CAN2 connector
- : for CAN devices like lambda modules, displays, keypads, etc.
- MAP connector
- : compatible with Link MAP sensors; adapter available for factory LS MAP sensors
- Knock sensor connector
- : supports up to two knock sensors, with adapters available for Gen 3 or Gen 4 factory sensors
- Alternator connector
- : for "F Body" alternators; provides exciter/lamp wire to terminal B
- Transmission ("Trans") connector
- : for reverse switch, DI, or other functions needing cabin signal
- IAC connector
- : for 4-wire stepper IAC; if no IAC is used, those channels may be used for other functions (boost valve, NOS, etc.)
- TPS connector
- : for cable-throttle sensors; if using DBW, may be repurposed
- DBW (electronic throttle) connector
- : for DBW throttle bodies, providing analog inputs, 5V, sensor ground; may be repurposed in cable-throttle engines
What's in the Box
- G4X StormX ECU
- (8 x Injector and 8 x Ignition Drives) - 108-4000
- Terminated Engine Harness GM LS GEN3/4*
- 101-0300
- LS Stepper Adapter Harness
- 101-0301
- LS MAP Adapter Harness
- 101-0302
- LS knock adapter loom
- 101-0305
- If you are after a fuse box and relay also, purchase this bundle here:
- 108-9010B
- Gen 4
- LS engines are better to consider this bundle:
- 109-9020B
- PCLink MAP Files
- Gen3 Cable Throttle Base Map for G4X XtremeX/StormX
- Harness Manual
- Online Instruction Manual
