Brian Crower Stage 3+ Cams 276 Supra 2JZGTE MK4 2JZ Camshafts with Timing Belt
Brand: Brian Crower
Part Number: BC0304/T215RB
Description:
Kit Contains Brian Crower Stage 3+ Cams BC0304 and Gates Racing timing belt part # T215RB.
Race Specification
Added lift profile for the ultimate high perf street/strip/drift application. Tuning and ECU mods recommended. Requires upgraded springs and retainers. Manufacturer recommends BC0310
2JZGTE CAMSHAFTS
The engine of choice for the fastest of the Sport Compact drag cars due to the tremendous power potential of Toyota's 2JZ-GTE, factory twin turbo engine. It is also used in Drifting with it's rear wheel drive setup. The 3.0-liter, inline six cylinder has proven itself to not only be capable of tremendous power output, but to also be extremely reliable. Made from 1994-1998, the 2JZGTE was employed in the Supra Mk IV chassis. The name is a combination of Celica and the word Supra. "Celica" is derived from Latin and its literal translation is "celestial" or "from the heavens". "Supra" is a word that is derived from latin that stands for "over, above, beyond, or greater than". So a translation to english would be something like "from above the heavens" for the entire term.
Gates Racing timing belt has three times more strength and durability. It has been specifically designed for high output and high RPM performance tuning applications. So not only does Gate Racing timing belt look different but it also is constructed with a high strength glass tensile cord to increase the performance and reliability.
The belt’s heat resistant elastomer compound withstands extreme heat and gives increased protection against cracking. The specially modified jacket material gives the timing belt increased tooth strength.
Fitment
-
Make: Toyota / Lexus
-
Model: Supra TT MK4 93-98 JZA80
-
Engine: 2JZ-GTE
Specifications
-
Note: Shimless Buckets Recommended & Inspect For 0.020" Miniminum Clearance from Casting / Cylinder Head Clearancing May be Required.
-
Cam ADV Duration: 276/276
-
Duration at 0.050: 234/238
-
Duration 050: 234/238
-
Cam Type: Intake & Exhaust
-
Cam lift txt: .405"/.405" (10.29mm/10.29mm)
Please note: This is a special order item by Stealth Ride. Usual wait times are 5–20 working days. If your order is urgent or you're concerned about potential delays, please contact us before purchasing.
