Link ECU Throttle Position Sensor TPSCW/CCW
Throttle Position Sensor clockwise/counter clockwise - 6 wire.
Brand: Link ECU
Part Number: 101-0100
Description:
The Link Throttle Position Sensor (TPSCW/CCW) is a high-precision, non-contact Hall Effect rotary position sensor designed for motorsport and high-performance automotive applications. Supporting both clockwise and counter-clockwise rotation, it delivers smooth, accurate throttle position feedback with exceptional durability, making it ideal for custom throttle body installations and harsh operating environments.
Suits
- All Link ECUs.
- Other aftermarket ECUs with analogue throttle position inputs.
- 8mm D-shaft throttle shafts.
- Clockwise and counter-clockwise throttle installations.
What's in the Box
- Throttle Position Sensor CW/CCW
- Printed Accessory instructions
Specifications
-
Highlights: The Link Throttle Position Sensor has the following specifications:; Supports clockwise and counter-clockwise operation.; Non-contact Hall Effect sensing technology.; 8mm D-shaft input.; Dual redundant outputs.; 32mm mounting bolt pattern.; 5V supply voltage.; IP68 environmental protection.; Operating temperature: -40degC to +125degC.; High-strength, temperature-resistant housing.; Over 50 million operating cycles.; 6-wire flying lead.
-
Product Dimensions: 540mm(L)x45mm(W)x20mm(H); 21.26in(L)x1.77in(W)x0.79in(H)
-
Product Weight: 25 grams (0.88 ounces)
-
Electrical: Operating Voltage Range: -0.5-5V; Maximum Input Voltage: 5V; Gauges of wire: 24AWG/0.2mm2
Notes
- Designed for use with 8mm D-shaft throttle shafts. Wiring instructions are included with the sensor.
